Устройство управления расходом жидкости, 100 см³/мин, 0,25 дюйма, тип Swagelok, DC 0–5 В, DB15, уплотнение Viton Модель: GE50A013102SMV020

Технические характеристики

• Type Mass Flow Controller
• Calibration Gas N2 (or equivalent)
• Full Scale Flow Range 100 sccm
• Maximum Inlet Pressure 150 psig
• Normal Operating Pressure Differential 10 to 40 psid
• Proof Pressure 1000 psig
• Burst Pressure 1500 psig
• Fitting Type 0.25 in. Swagelok-style
• Control Range 2 – 100 sccm
• Flow Input Output Signal 0 – 5 VDC
• Connector Type 15-pin D-sub (tied grounds)
• Typical Accuracy ±1% of set point for 20 to 100% Full Scale, ±0.2% of Full Scale for 2 to 20% Full Scale
• Repeatability ±0.3% of Reading
• Resolution 0.1% of Full Scale

• Zero Temperature Coefficient
• Span Temperature Coefficient
• Inlet Pressure Coefficient
• Typical Settling Time
• Warm-up Time 30 minutes
• Operating Temperature Range 10 – 50°C
• Storage Humidity 0 to 95% Relative Humidity, non-condensing
• Storage Temperature Range -20 to 80°C
• External Leak Integrity -09 (scc/sec He)
• Leak Integrity Through Closed Valve Up to 10K valve
• Wetted Materials 316L S.S. VAR, 316 S.S., Elgiloy®, Nickel
• Seal Material Viton
• CE Certified Yes
