Technical dataKL2502
Number of outputs 2
Nominal voltage 24 V DC (-15%/+20%)
Load type ohmic
Max. output current 0.1 A (1 A driver component) per channel
PWM clock frequency 1 Hz…20 kHz, 250 Hz default
Duty factor 0…100% (pulse duration TON > 750 ns, pause duration TOFF > 500 ns)
Resolution max. 10 bit
Electrical isolation 500 V (K-bus/field potential)
Current consumption power contacts typ. 10 mA + load
Current consumption K-bus typ. 18 mA
Bit width in the process image 48 inputs/outputs: 2 x 16 bit data, 2 x 8 bit control/status
Configuration no address setting, configuration via Bus Coupler or controller
Weight approx. 50 g
Operating/storage temperature 0…+55°C/-25…+85°C
Relative humidity 95%, no condensation
Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission conforms to EN 61000-6-2/EN 61000-6-4
Protect. rating/installation pos. IP20/variable
Pluggable wiring for all KSxxxx Bus Terminals
Approvals/markings CE, UL, ATEX, IECEx, cFMus
Ex marking ATEX:
II 3 G Ex ec IIC T4 Gc
IECEx:
Ex ec IIC T4 Gc
cFMus:
Class I, Division 2, Groups A, B, C, D
Class I, Zone 2, AEx ec IIC T4 Gc
