Манометр мини-конвектрон с дисплеем 0,125 дюйма NPT, нелинейный аналог, 2 реле, вольфрам Модель: 275600-2-GP-T

Технические характеристики

• Type Vacuum Module
• Display 3-digit green LED
• Vacuum Pressure Range 1.0 x 10-4 to 1000 Torr
• Analog Output 0.375-5.659 VDC (0-1000 Torr Non-linear)
• Orientation Horizontal preferred
• Fitting Type 0.125 in. NPT male
• Set Point Relays 2
• Relay Contact Rating 1 Amps at 30 VDC resistive, AC non-inductive
• Internal Volume 40 cm3 (2.5 in3)

• Filament Gold-plated Tungsten
• Exposed Materials 304 stainless steel, borosilicate glass, Kovar, alumina, NiFe alloy, polyimide
• Power Requirements 11.5 – 26.5 VDC, 0.1 Amps at 11.5 VDC, 1.6 Watts maximum, 1.8 maximum (with display)
• Maximum Bakeout Temperature 150°C with electronics removed
• Operating Temperature Range 0 – 40°C ambient, non-condensing
• Storage Temperature Range -40 – 70°C
• Electrical Connector 15-pin subminiature-D male
• CE Certified Yes
