Yamato DP-43C — программируемая большая вакуумная сушильная печь, 91 л, 220 В

Description

Yamato DP-43C

• Internal capacity: 91L
• Power source: 220V
• Calibration off-set function
• Interactive key input of the control panel for easy operation
• Easy removal of piping and maintenance of the vacuum pump

Programmable Large Vacuum Drying Oven, 91L, 220V

The Yamato DP-43C is a large capacity vacuum drying oven with enhanced safety features: sensor trouble detection, SSR short circuit detection, heater disconnection detector(sensor), memory error, internal communication error, overheating, and measurement temperature error. Large observation window with protective cover for increased safety.

Cotrol Panel

Method

DP Series Comparison

DP43CDP63CMax. Temp. Reaching Time~80 min.~120 min.HeaterMica heater, 2.25 kWMica heater, 3.15 kWInternal Dimensions WxDxH450×450×450 mm600×600×600 mmExternal Dimensions WxDxH670×669×1500 mm820×819×1650 mmInternal Capacity91L216LShelf Support Qty. / Pitch4 steps / 105mm4 steps / 140mmExhaust Port / Purge PortNW25 flange / Rc 1/4 (18mm O.D.)NW25 flange / Rc 1/4 (18mm O.D.)Power Source220V, single-phase, 11A (no plug, round terminal)220V, single-phase, 15A (no plug, round terminal)Weight~190kg~290kg
