Yamato DG-450C – сушильный шкаф для стеклянной посуды с естественной конвекцией и лампой стерилизации, 92 л, 220 В

Description

Yamato DG-450C

• Internal capacity: 92L
• Power source: 220V (no plug, round terminal)
• Installed with filter at air in-take port, exhaust fan and germicidal lamp for fast drying
• Large window for easy observation
• Stainless steel interior, easy to clean and highly resistant to corrosion

Glassware Drying Natural Convection Oven w/Sterilization Lamp, 92L, 220V

Natural convection oven for glassware drying

Operation and functions

• Large window for easy observation
• Can be used to store instruments after drying
• Highly efficient heat insulation material for both internal and external structure
• Adjustable foot for stability on uneven floors
• Mobile on casters (DG800C/810C/840C/850C)
• Equipped with stainless steel pipe heater and water receiving plate at the bottom
• Stainless steel interior, easy to clean and highly resistant to corrosion
• DG440C/450C/840C/850C installed with filter at air in-take port, exhaust fan and germicidal lamp for fast drying
• Dial setting and digital display of temperature control and timer

Safety features

• Self-diagnostic functions, calibration offset, independent overheat prevention, over current leakage breaker, key lock and auto recovery after power failure

(Note: Accurate temperature control may not be possible with heat generating samples in the chamber)

Control Panel

Germicidal lamp

Water receiving plate

Air in-take filter

DG Series Comparison

SKU

DG400C

DG410C

DG440C

DG450C

DG800C

DG810C

DG840C

DG850C

Exhaust PortI.D. 34mm × 2Axial flow fan forced exhaustI.D. 34mm × 2Axial flow fan forced exhaustSuction PortI.D. 30mm × 2Set air suction filterI.D. 30mm × 2Set air suction filterGermicidal Lamp–15W×115W×115W×1Int. Dim. (WxDxH)450×450×450 mm450×450×450 mm620×600×1195 mm620×600×1195 mmExt. Dim. (WxDxH)504×562×788 mm504×562×820 mm674×711×1586 mm674×711×1618 mmInternal Capacity92L92L445L445LObservation WindowStandard glass 3mm W250 x H300mmStandard glass 3mm W250 x H300mmStandard glass 3mm W250 x H700mmStandard glass 3mm W250 x H700mmShelf Plate / Bracket2pcs. / 4pcs.2pcs. / 4pcs.4pcs. / 8pcs.4pcs. / 8pcs.HeaterSUS pipe heater 1.0kWSUS pipe heater 1.0kWSUS pipe heater 1.34kWSUS pipe heater 1.34kWWeight~45kg~48kg~78kg~83kg
