MW Series Micro Powder Mill

MW series micro powder mill is a new kind of mill which is developed with more than 20 years’ experience of manufacturing grinding mills and absorbed and adopted foreign advanced technology. It is mainly used to grind low or medium hard raw materials.

Applications:

• Chemical Industry
• Paint
• Cosmetics
• Medicine
• Food Additive

Specifications – Technical Data

• Production Capacity: 1.5-12 Tons / Hour
• Maximum Feed: ≤20
• Quantity of grinding ring (layer): 4
• Overall Dimension: 27320*4500*10250 mm

Advantages of MW1280 Micro Powder Mill

• Low investment cost.
• High output rate of finished powders.
• Long life of tear and wear parts.
• Operation in grinding cavity, safe and reliable.
• Super fine finished powders.
• Environmental friendly, no pollution.

Технические характеристики

Characteristics

• Technology: roller
• Orientation: vertical
• Product application: for powders
• Final grain size:
  • Min.: 6 µm
  • Max.: 45 µm
• Rotational speed:
  • Min.: 135 rpm (848 rad.min-1)
  • Max.: 155 rpm (974 rad.min-1)
• Output:
  • Min.: 1,500 kg/h (3,307 lb/h)
  • Max.: 12,000 kg/h (7 lb/h)
• Motor power: 185 kW (252 hp)
• Machine width: 4,550 mm (179 in)
• Machine height: 10,250 mm (404 in)
