UNI-T UTS1032T – Benchtop Spectrum Analyzer (9kHz – 3.2GHz) with Tracking Generator

Description

UNI-T UTS1032T

• Frequency measurement range: 9kHz – 3.2GHz
• This version includes a tracking generator
• 10.1” multi-touch HD screen with gesture support
• Display average noise level can be as low as -161 dBm (typical value)
• 4 traces are provided to facilitate comparative observation and find abnormal signals

Benchtop Spectrum Analyzer (9kHz – 3.2GHz) with Tracking Generator

The UNI-T UTS1000B/T series are swept spectrum analyzers with a frequency range from 9kHz to 3.2GHz (model dependent) and are suitable for use in many different applications.

The chart below outlines several main features of each.

ModelFrequencyTracking GeneratorUTS1015B9kHz – 1.5GHzNoUTS1015T9kHz – 1.5GHzYesUTS1032B9kHz – 3.2GHzNoUTS1032T9kHz – 3.2GHzYes

Excellent sensitivity to test weaker signals

Weak signals are easily affected by the noise floor of the spectrum analyzer itself. The UTS1000B/T series features a displayed average noise level (DANL) as low as -161dBm, which is very useful when working with weak test signals.

Four traces

The UTS1000B/T provides four traces to facilitate comparative observation and find abnormal signals.

10.1 inch HD screen with gesture support

The UTS1000B/T features a 10.1” multi-touch screen which supports multiple gesture functions including dragging, expanding, and zooming.

EMI pre-compliance analysis (option UTS1000B-EMI)

When used with optional near-field probes (part number UTS-EMI01), software option UTS1000B-EMI can help you find and improve EMI defects in advance, shortening the development cycle.

Advanced measurement kit (option UTS1000B-AMK)

The advanced measurement kit provides several additional measurement functions for the UTS1000B/T. Functions include channel power, adjacent channel power, occupied bandwidth, carrier noise ratio, harmonic measurement, and more.

Front panel layout

1. 10.1” touch screen7. Tracking generator (T models only)2. Measurement keys8. Speaker3. Advanced function keys9. 3.5mm headphone jack4. Utility keys10. USB inputs (external USB, keyboard, mouse)5. Data controls11. On/off6. RF input

Rear panel layout

1. 10MHz reference input7. Power switch2. 10MHz reference output8. Power cord input3. Trigger in9. Lock4. HDMI10. Handle5. LAN11. Dust proof cover6. USB device
