UNI-T UTi120B – 120 Heavy Duty Series Thermal Imager

Description

UNI-T UTi120B

• 120×90 pixel IR resolution
• -4°F to 752°F temperature range
• 50°×38° field of view
• 25Hz refresh rate
• 2.8in (320×240 Pixels) TFT LCD display

120 Heavy Duty Series Thermal Imager

The UTi120B is a robust and ergonomically designed thermal camera, combining powerful performance with user-friendly features at an economical price. With a resolution of 120×90 pixels in the infrared spectrum, it automatically tracks temperatures ranging from -4°F to 752°F. This thermal camera serves as an affordable professional troubleshooting tool, finding wide applications in various fields.

Different Versions Available

Two versions of the B series heavy duty thermal imagers are available. Please see the table below for an overview of some of the differences.

UTi120BUTi260BResolution 120px X 90px256px X 192px FOV 50° x 38° 56° x 42°Max Temp 752°F 1022°F

Designed for Industrial Use

Handheld thermal cameras are designed for a variety of industrial applications. These ergonomically designed products can minimize fatigue when using for long periods of time. This series uses high-performance infrared detectors, allowing wide temperature measurement range and accurate data, and are suitable for professional analysis work.

Applications

Applications include PCBA inspection, motor inspection, pipeline inspection, house water leakage inspection, automotive maintenance, solar panel inspection, power distribution cabinet inspection, electricity facilities inspection, mechanical equipment inspection, heating equipment inspection, and building & HVAC inspection.

Useful Features

• Image fusion captures a real-time IR image and displays the measured temperature
• Color palette selection allows for selection of palettes including Iron Red, White Hot, and Red Hot
• Center point and high/low temperature of measured can be tracked
• High/low temperature alarm warn user when a predetermined temperature has been measured
• Alarm temperatures can be set the user in a configuration menu
