Ультразвуковой толщиномер DMS 2 с функциями A-Scan и B-Scan Снят с производства

Product Information Advanced Thickness Measurement

• No need to remove coatings (paint) measure through coatings without including the coating layer in the digital thickness reading
• Stable high-temperature measurement up to 1000ºF with HT400A probe and armor jacketed cable
• MIN CAP captures the minimum thickness for a series of measurements and displays the associated A-Scan (32 Hz acquisition rate)
• DIALOG Intelligent Probes are automatically recognized for optimum instrument setup, performance, and documentation
• Automatic probe zero corrects for delay line dimensional changes (wear & growth)
• 8 Hz selection updates the display twice as fast as normal for immediate response and enhances test results when movement of the probe is necessary vs. spot testing
• SIP mode utilizes single-element probes for attenuative or thick materials
• Gain is readily adjustable in 1 dB steps via a direct access key
• Freeze locks the A-Scan display for evaluation and verification of the echoes, makes time base parameter adjustments easy
• 4 band passes automatically optimize the receiver bandwidth to match the frequency of the probe for best results
• RF display provides additional waveform information to assist with difficult measurement applications (DMS 2 only)

Easy to Use

• Direct access keys are at your fingertips for immediate adjustment of operating parameters
• Convenient color coded keypad layout
• Frequent text messages guide operation
• Compact, comfortable, one-hand control (left or right hand)
• TEST key simulates a home key to jump to test/measurement menu
• Dual/Dual-Multi hot key allows for fast toggle between Dual and Dual-Multi (thru-coat) modes
• Store/recall 20 parameter sets for fast instrument setup and repeatable test results
• Lockable keypad prevents accidental changes to operating parameters

Rugged, practical packaging…

• Custom molded, gasket-sealed, high-impact resistant plastic housing for dependable trouble free use
• Robust, rubber case for added protection in tough field environments
• Padded hand strap, neck strap, waist belt, & prop-up stand are convenient features of the rubber case • Full week”s work (40 hours) of use on 4 standard AA alkaline batteries no special battery packs or battery chargers needed
• I/O & AC power connectors plugged by the rubber case to prevent connector contamination

Технические характеристики
