TREND Networks POEPRO-KIT Bundle – PoE Pro POE Tester + Amplifier Probe, Accessories, 3 Year Warranty

Description

TREND Networks POEPRO-KIT Bundle – PoE Pro POE Tester + Amplifier Probe, Accessories, 3 Year Warranty

The new PoE Pro eliminates guesswork when installing, maintaining and troubleshooting networks where PoE is deployed.

Previously technicians had to understand all the various standards, device power outputs and cable lengths to be sure a device will operate successfully.

The PoE Pro identifies the Class of the PoE source and power available to a PoE device regardless of cable length, cable quality or other factors.

• No more trial and error Accurately measure the maximum power available
• Supports PoE up to 90W (PoE++) Test all PoE Classes (0-8) and Types (af/at/bt)
• Identifies the powered pairs Helps to determine PoE switch or mid-span injector
• Verify the PoE installation Pass / Fail indication to IEEE standards
• Extended Power Test Some switches may provide power exceeding their IEEE Class rating. Measure the maximum available power up to 90 watts
• Plus all the familiar cable testing features of the VDV II Pro

Cable Verification and Troubleshooting

Accurate fault-finding that saves time and money

The PoE Pro utilizes Time Domain Reflectometry (TDR) to accurately measure cable length and provide distance to fault information. This Speeds up fault finding as well as minimizes disruption and potential damage to fixtures and fixings.

Instant results

With comprehensive details on faults such as opens, shorts, crossovers and split pairs, PoE Pro identifies wiring errors instantly.

No need for separate testers

The integrated RJ11/RJ12 (voice), RJ45 (data) and F-Type (video) connectors allow faster testing of most types of low-voltage cables by eliminating the need for separate testers.

Validate voice and data services faster

PoE Pro quickly determines which media service is running over the cable, such as Ethernet, ISDN, PBX and PoE resulting in faster fault diagnosis.

Quickly determine network speed

Troubleshooting active Ethernet networks is also made easier with in-built network detection that displays the speed (10/100/1000) and duplex (Half/Full) status of a network port.

Voltage protection for your tester

The PoE Pro will detect high voltages and provide a visible and audible warning to prevent damage to the tester.

Cable tracing to save time

The analog/digital tone generator with multiple tones can be used with most analog and digital cable tracing probes which is essential for finding faulty or mislabeled cabling.

Port identification

The port blink function will identify the switch port to which a cable is connected.
