The FTIR spectrophotometer is a new cube-corner type Michelson interferometer which is compact with high stability and less sensitivity to vibrations and thermal variations than conventional Michelson interferometers. It is fully sealed for damp and dust-proof operation with built-in desiccant, viewable observation window, accuracy and reliability.

Features:

• Isolated IR source and large space heat dissipation chamber
• High intensity IR source adopts a reflex sphere to retain even and stable IR radiation
• Cooling fan for mechanical stability
• Super wide sample compartment for flexibility
• Programmable gain amplifier, high accuracy AID converter and embedded computer
• Connects to PC via USB port for automatic control and data export
• Compatible PC control and software
• Various special IR libraries are available for routine searches, libraries can be added or set up
• Accessories available: Defused/specular reflection, ATR, liquid cell, gas cell, and IR microscope can be mounted

Specifications:

Model: EM-FTIR-SPEC

Spectral Range: 7800 to 350 cm^-1

Resolution: Better than 0.85 cm^-1 (WQF-510A)

Better than 0.85 cm^-1 (WQF-520A)

Wavenumber Precision: ±0.01 cm^-1

Scanning Speed: 5 step adjustable for different applications

Signal to Noise Ratio: Better than 15000:1 (RMS value at 2100 cm^-1, resolution 4 cm^-1, detector DTGS, 1 min data collection)

Beam Splitter: Ge coated KBr

Infrared Source: Air cooled, high efficiency, reflex sphere module

Detector: DTGS

Data System: Compatible computer

Software: FT-IR software contains all routines needed for basic spectrometer operations including library search quantitation and spectrum export

IR Libraries: 11 IR libraries included

Dimensions: 540 x 520 x 260 mm

Weight: 28 kg
