Rohde & Schwarz NGC103-G – Three-Channel DC Power Supply (32V, 3A, 100W, USB/LAN/GPIB)

Description

Rohde & Schwarz NGC103-G

• Three DC output channels
• Max 32V, 3A, 100W (total) outputs
• Linear postregulation for low residual ripple and noise
• Electronic fuse (OCP), adjustable maximum voltage (OVP), adjustable maximum power (OPP) and overtemperature protection (OTP)
• USB/LAN/GPIB interfaces

Three-Channel DC Power Supply (32V, 3A, 100W, USB/LAN/GPIB)

Rohde & Schwarz NGC100 DC power supplies are very energy efficient and remain cool and quiet, even at maximum load. Practical interfaces and connectors make work quick and convenient, while special applications have dedicated functions. A wide range of functions and fundamental specifications make Rohde & Schwarz NGC100 DC power supplies ideal for development labs, industrial environments, manufacturing, and educational institutions.

Several Versions Available

Several versions of the NGC100 series are available, differing in number of channels and output specifications. Note the options with GPIB. You must order that model if you need a GPIB interface, this feature cannot be retrofitted to a standard model.

Channels Max Power per Channel Output Voltage per Channel Output Current per ChannelGPIBNGC101 1 100 W 32 V 10 Amp NoNGC101-G 1 100 W 32 V 10 Amp YesNGC102 2 50 W 32 V 5 Amp NoNGC102-G 2 50 W 32 V 5 Amp YesNGC103 3 33 W 32 V 3 Amp NoNGC103-G 3 33 W 32 V 3 Amp Yes

Informative Display Area

1. Device status bar indicates master on/off status, current power consumption, and state of selected interfaces and functions

2. Interactive softkey menus provide for navigation

3. Channel display area colors change depending on operating mode

4. Channel status bar displays the state of the indicators available in the device channel

5. Statistic function displays minimum, maximum, mean, and count for voltage and current for each channel

Easy Ramp

• The EasyRamp function can output a constant rise of the supply voltage
• The output voltage can be increased continuously within a 10 ms to 10 s timeframe
• Each channel can be configured independently on power supplies with more than one channel

Parallel and Serial Operation (Select Models)

• Available on select models (multichannel only)
• Because all channels are electrically equivalent, they can be combined in serial mode to achieve higher voltages. Up to 96 V can be achieved with the NGC103.
• In parallel mode, the channels can be bundled for higher current. Up to 10 A can be achieved when two channels of the R&S NGC102 are combined.
• See individual unit specifications for exact capabilities

Sequencing (Select Models)

Sequencing enables you to run connected available channels consecutively with adjustable time offsets when the master output is switched on. It is also possible for all channels to be simultaneously switched on or off. The time offset between each channel can be adjusted between 1 ms to 10 s. The sequencing function is activated and deactivated individually for each channel. Additionally, the sequencing function can be activated by means of a manual trigger.

*Note: Available on select models (multichannel units only)
