Rigol DG5252 Pro – Генератор сигналов произвольной формы (2 канала / 250 МГц)

Description

Rigol DG5252 Pro

• Two channels
• 250 MHz maximum frequency
• 2.5 GSa/s maximum sample rate
• 64 Mpts/ch maximum arbitrary waveform length (128 Mpts/ch via option DG5000 Pro-2RL)
• Optional functions: Sequence, IQ, Multi-pulse, Pattern, Multi-tone

Function/Arbitrary Waveform Generator (2 Channel / 250 MHz)

The Rigol DG5000 Pro is a multi-functional and cost-effective dual-channel function/arbitrary waveform generator.

With up to 2.5 GSa/s sample rate and 64 Mpts/CH memory depth (128 Mpts/CH optional), the DG5000 Pro is an all-in-one device which integrates Function Generator, Arbitrary Waveform Generator, Noise Generator, Pulse Generator, Harmonics Generator, and Analog/Digital Modulator.

DG5252 ProDG5352 ProDG5502 ProMaximum frequency250 MHz350 MHz500 MHzNumber of channelsTwoTwoTwoMaximum sample rate2.5 GSa/s2.5 GSa/s2.5 GSa/sVertical resolution16 bit16 bit16 bitWaveform memory depth (Mpts/ch)64 (std), 128 (opt)64 (std), 128 (opt)64 (std), 128 (opt)

Dual channel ground isolation

Eliminate interference and noise caused by ground loops, improve output stability, and protect devices and circuits that are sensitive to potential differences.

Built in harmonic generator

The harmonic generator (20th order maximum) provides a precise measurement method for performance testing of devices such as high-order filters and amplifiers.

Several options available

Rigol offers several options for the DG5000 Pro, enabling users to customize the instrument for their specific application.

• IQ Modulation – DG5000 Pro-IQ
• Multi-pulse Output – DG5000 Pro-MPUL
• Advanced Sequence Function – DG5000 Pro-SEQ
• Multi-tone – DG5000 Pro-MTONE
• Pattern – DG5000 Pro-PJ
• 128 Mpts/CH (Max.) Arb Length Upgrade – DG5000 Pro-2RL
• Function Bundle with DG5000 Pro-IQ/MPUL/SEQ/MTONE/PJ/2RL – DG5000 Pro-BND

Optional battery pack (part # BatHolder138)

It is possible to power the DG5000 Pro with an optional battery pack for outdoor and mobile usage, enabling hours of usage where no AC power is available. The battery pack provides a greater level of versatility, with tests no longer being confined to the lab.

Front panel

1. 10.1” touch screen9. CH2 sync output/trigger output (Sync Out),Mod In connector2. Output modes10. CH2 output3. Frequency/period/phase/delay11. CH1 sync output/trigger output (Sync Out),Mod In connector4. Waveform selection 12. CH1 output5. Amplitude/high, offset/low13. Help, trigger, align keys6. Parameter input14. USB host7. Shortcut keys15. Power switch8. Channel controls

Rear panel

1. 10 MHz REF out7. Security keyhole2. 10 MHz REF in8. AC input3. VESA pattern (100×100)9. Fuse4. HDMI10. Battery connector5. USB device11. Aux out6. LAN12. Aux in
