Psiber PRO7515 PingerPro+ Fiber Cable and Network Management Tester + CT15

Description Cable and network management tool for network managers & technicians

Thousands of network professionals have relied on Psiber test tools for installing, troubleshooting and maintaining complex, high-performance networks.

The PingerPro’s extensive features make it even easier for managers and technicians to meet the growing challenges of cable and network management.

The PingerPro brings a new level of connectivity testing with fault location, Gigabit Ethernet capability, advanced IPv6 support, Logical Link Data Protocol (LLDP/CDP/EDP) and a powerful feature set that you will use every day. As a result, the PingerPro is the complete high-performance first-response-tool, designed to solve your most frequent network problems.

Installing new network drops or devices, monitoring performance or troubleshooting problems.

The PingerPro touch screen interface lets you select discrete tests or a configurable AutoTest that provides critical Link information, conducts network connectivity tests and provides switch port information in seconds. The PingerPro provides critical, clear and easy to read answers.

Document your test results with a few keystrokes, to prove the job’s done right. The rechargeable battery pack and rugged weather-resistant design, lets you test anywhere. The PingerPro is always available.

Network Test Features

Link Tests

• Verify Link Connection
• Identify Port Speed (10/100/1000baseT) and Duplex
• Selectable Speed/Duplex or Auto-negotiation

Ping Tests

• Verify Connectivity across a Network or the Internet
• Measure Packet Round Trip Time
• Count Packets Received, Lost or Corrupted

Configurable Ping Test

• Single, Continuous or Burst of Ping Packets
• IPv4 or IPv6

Trace Route

• Show Packet Route across a Network or the Internet

Device Emulation

• MAC Cloning/Spoofing

Switch Port Information

• Supports Link Layer, Cisco and Extreme Discovery Protocol (LLDP/CDP/EDP)
• Provides Port Speed and Duplex, VLAN, Switch Model, Port Number, and More

(Note: Information Varies by Manufacturer and Switch Model).

AutoTest

• Performs Selected Tests in Seconds
• Allows Rapid Testing of Large Numbers of Ports
• Saves Test Results Quickly with Automatic File Naming
• Store up to 1000 Tests

Security

• IEEE 802.1x Port-based Network Access
• Provides User Name and Password Authentication (EAP-MD5)

PingerPro Tools

(PC Based Software)

• Download Test Results to Review and Generate Professional Reports
• Install Firmware Updates

Cable Test Features

Cable Length and Fault Location

• Measures the Length of Each Wire Pair
• Provides the Distance to Open or Short Cable Faults

Wire Map

• Graphical, Color Display of Wire Connections
• Identifies Opens, Shorts, Mis-wires and Split Pairs
• Measures all Pin Pair Combinations for Highest Accuracy
• Easy Detection of Remote Wiremap Terminator Verified by Icon and Audio Alert

Port ID

• Flashes the Link LED on a Connected Switch Port

Tone Generator for Cable Tracing

• Generates 5 Different Selectable Tones for Tracing Cables
• Optional CableTracker Probe (CT15) Available for Cable Tracing

Power over Ethernet (PoE) Testing

• Measure PoE and PoE+ Voltage and Power to Determine Switch Port Power Allocation

Human-Centered Design Features

• Rugged Weather Resistant Case
• Rechargeable Li-ion Battery
• Color Touch Screen Interface
• Cable Management Brackets
• Tilt Stand
• Built-in Help Screens
• Multiple Language Support

Fiber Test Features

• Test Fiber Links
• Verify Connectivity over Multimode (850nm) and Single-Mode (1310nm) Links
• 1000BaseX
• Optional 100baseFS

Optical Power Meter

• Measure Received Optical Power Levels
