The Matrix MCR-5200

The Matrix MCR-5200 is a high quality multifuntional LCR meter used to test electronic components. The meter has a wide test frequency band of 40Hz – 200kHz that is divided in 41 frequency points. Measurements can be done with 8 different test signal levels at an measurement accuracy of 0.1%. This allows the measurement requirements of very different components to be met.

The meter has a 5-digit, 4.3 inch LCD screen on which the direct reading, Δ% or V/I ratio can be displayed. Furthermore, the MCR-5200 features multiple interfaces like RS232 (back), USB (front). There is also a memory where more than 100 sets of internal instrument settings can be stored/recalled.

Технические характеристики

• |Z|, R, X, ESR: 0.1mΩ-99.999MΩ
• C: 0.01pF-9.9999F
• L: 0.01μH-99999H
• D: 0.0001-9.9999
• Q: 0.0001-9999.9
• θ Deg/Rad: -179.99°-179.99°/-3.1416-3.1416
• Test frequency: 40 Hz – 200 kHz (41 frequency steps, see manual for more information)
• Test signal level: 0.05V, 0.1V, 0.2V, 0.25V, 0.3V, 0.4V, 0.5V, 1V
• Measurement accuracy: 0.1%
• Range/Trigger functions: automatic, hold, manual selection/internal, manual, external, bus
• Measurement speed: 3/10/30 times/s
• Display: 5-digit, 4.3 LCD
• Interfaces: RS232C, handler, USB (front)
• Dimensions: 240x100x330 mm
• Weight: 3.8 kg

The MCR-5200 comes by default with:

• 2x spare fuses
• Power cable
• Kelvin clips (BNC)
