Phase II+ UTG-4000 Ultrasonic Thickness Gauge with A and B Scan

Description Phase II+ UTG-4000 – Ultrasonic Thickness Gauge with A and B Scan

• Designed to measure the thickness of metallic and non-metallic materials
• Packed with features typically found on high-end models only
• Display readings in either inch or millimeter

Utilizing color waveform A-scan and time-based B-scan for absolute correctness, this new state of the art ultrasonic thickness gauge is packed with useful features allowing users to be confident of the displayed values on the most critical of applications. This multi-functional ultrasonic thickness gauge offers everything from basic measurement, Scan mode with Min/Max viewing, GO/NO GO display, Adjustable Sound Velocity, and Thru-Coating Capabilities. This dynamic ultrasonic thickness gauge is designed to measure the thickness of metallic and non-metallic materials in critical situations that ordinary thickness gauges couldn’t do.

The UTG-4000 ultrasonic thickness gauge will accurately display readings in either inch or millimeter after a simple calibration to a known thickness or sound velocity.

Blanking

Configuration Mode

Differential Mode

Adjustable Gate

Alarm Mode

Min / Max Mode

Color B Scan

Phase II Ultrasonic Thickness Gauge Comparison Model UTG-1500 UTG-2800 UTG-2900 UTG-4000 UTG-2650 Probe Type 5 MHz Dual Element 5 MHz Dual Element 5 MHz Dual Element 5 MHz Dual Element Single Delay Line Mode Single Echo Single Echo Single Echo
& Multiple Echo
Single Echo
& Multiple Echo
Single Echo
& Multiple Echo
Measurement Range 0.05” to 8.0” 0.04′ to 12.000′ Single Echo: 0.03′ to 23.000′
Mult. Echo: 0.118” – 3.50” Steel (up to 35mil coating)
Single Echo: 0.02′ to 20.000′
Mult. Echo: 0.118” – 3.50” Steel (up to 35mil coating)
Single Echo: 0.059′ to .787′
Mult. Echo: 0.012” – 0.394”
Thru-Paint Capability No No Yes Yes No Adjustable Sound Velocity Yes Yes Yes Yes Yes A-Scan/B-Scan No No No Yes No Memory/Data Output No Yes: 20 groups (up to 99readings/group) / USB Yes: 20 groups (up to 99readings/group) / USB Yes: 20 groups (up to 99readings/group) / USB Memory: 500 values / No Output Measurement Rate – Normal 3 readings/sec 4 readings/sec 4 readings/sec 4 readings/sec 4 readings/sec Measurement Rate – Scan N/A 10 Readings/sec 16 Readings/sec 16 Readings/sec N/A Resolution 0.001′ / 0.01 mm 0.001′ / 0.01 mm 0.001′ / 0.01 mm 0.001′ / 0.01 mm 0.001′ / 0.0001′ Selectable Accuracy .5%+.2mm .5% +0.001′ .5%+0.001′ 0.001”(up to 0.984”)
0.007”(up to 3.03”)
0.019”( 4” and above)

0.0002′ (below 3mm)
0.002′ (if below 20mm)
Gage Dimensions 161x69x32mm 150x74x32mm 150x74x32mm 153x76x37mm 149x73x42mm Weight (without batteries) 10.5oz. 8.6 oz. 8.6 oz. 9.9 oz. 5.6 oz. Warranty 5 Years 5 Years 5 Years 5 Years 5 Years List Price $595.00 $795.00 $995.00 $2,895.00 $1,995.00
