The Mitutoyo bore gage with micrometer head delivers a wide range of bore measurement capabilities for high accuracy at 2µm. Interchangeable anvils made of alloy steel attach to the micrometer head for accurate dimensional setting. The anvils feature a carbide-tipped ball for better measurement reliability and longevity.

  • Includes a Mitutoyo Dial Indicator
  • Available in Metric models
  • Metric models have a graduation option of 0.01mm and 0.001mm
  • Optional extension rods are available to measure deeper bores and holes
  • Large, newly designed hollow grips are easier to hold and reduce heat transfer from the operator for better accuracy
  • Models with dial indicators are fully protected by a rugged cover
  • Gage stem diameter is 8mm
  • Interchangeable anvils are constructed of alloy steel with carbide-tipped measuring faces for added accuracy and durability
  • Includes various anvils and spacers depending on size of gage ordered
  • Supplied in a fitted plastic case

Order No.: Product Image: Range: Graduation: Dial Gage: Max Measuring Force: Max Guide Force: Mic head travel: Sub anvil:

Order No.:

511-813-20 – 60 – 100mm 0.01mm 2046AB 5N 10N 10mm 10, 20mm
511-814-20 – 100 – 160mm 0.01mm 2046AB 5N 10N 13mm 10, 20mm
511-815-20 – 150 – 250mm 0.01mm 2046AB 6N 15N 13mm 10, 20, 50mm
511-816-20 – 250 – 400mm 0.01mm 2046AB 6N 15N 25mm 50, 25mm
511-817-20 – 400 – 600mm 0.01mm 2046AB 6N 20N 50mm 50, 100mm
511-818-20 – 600 – 800mm 0.01mm 2046AB 6N 20N 50mm 50, 100mm
511-823-20 – 60 – 100mm 0.001mm 2109AB-10 5N 10N 10mm 10, 20mm
511-824-20 – 100 – 160mm 0.001mm 2109AB-10 5N 10N 13mm 10, 20mm
511-825-20 – 150 – 250mm 0.001mm 2109AB-10 6N 15N 13mm 10, 20, 50mm
511-826-20 – 250 – 400mm 0.001mm 2109AB-10 6N 15N 25mm 50, 25mm
511-827-20 – 400 – 600mm 0.001mm 2109AB-10 6N 20N 50mm 50, 100mm
511-828-20 – 600 – 800mm 0.001mm 2109AB-10 6N 20N 50mm 50, 100mm

511-813-20
511-814-20
511-815-20
511-816-20
511-817-20
511-818-20
511-823-20
511-824-20
511-825-20
511-826-20
511-827-20
511-828-20

Технические характеристики

Technology: Mechanical
Contact Point: Carbide ball
Units: Metric
Accuracy: +/-2µm
Repeatability: 0.5µm
Adjacent Error: 1µm
Stem Diameter: 8mm
With Dial Gage Protective Cover (21DZA000): Yes
