Описание продукта

Features:

• Independent topology
• 60 μs single-channel operate time
• Maximum drive current, 600 mA per channel, 25 A per module
• 50 V maximum drive voltage, external power
• Internal drive power, 5 V at 1.25 A, 12 V at 0.5 A
• Controls up to 64 external relays

The PXI-2567 is an external relay driver that works with internal or external power sources. The PXI-2567 allows you to control relays when the current and voltage requirements for those relays exceed the capabilities found in existing relay modules or for relays embedded in a test system. The PXI-2567 includes overcurrent, overvoltage, and flyback protection to ensure long-life operation. The PXI-2567 can also drive small DC motors or other inductive relay coils.
