Описание

Agilent Seahorse XFe96 Analyzers measure the oxygen consumption rate (OCR) and extracellular acidification rate (ECAR) of live cells in a 96-well plate format.

OCR and ECAR rates are key indicators of mitochondrial respiration and glycolysis as well as ATP production rate. Together these measurements provide a systems-level view of cellular metabolic function in cultured cells and ex vivo samples.

Спецификации:

• Amperage: 9 A
• Analyzer Application: Phenotyping Screening
• Assay Running Volume: 150 – 275 µL/well
• Assay Wells: 92
• Communication: TCP/IP, USB, wireless
• Controller Description: Combination of Windows 10 computer and touchscreen display with full assay design, control, and analysis capability
• Controller Touchscreen: Yes
• Controller Type: Cable-connected
• Depth: 43 cm
• Height: 61 cm
• Injection Ports per Well: 4 per well
• Memory: 16 GB
• Microchamber Volume: 2.8 µL
• Operating Environment Relative Humidity: 20 – 80 %
• Operating Environment Temperature: 4 – 30 °C
• Operating Voltage: 100 – 240 VAC
• Sample Requirements: 5000 – 500000 cells/well
• Sample Temperature: 16 – 42 °C
• Software Included: Wave Controller, Windows 10 Enterprise, Wave Desktop unlimited use license
• Volume per Port Injection: 25 µL
• Weight: 23 kg
• Width: 41 cm
