General Meditech G1B Handheld Pulse Oximeter

General Meditech G1B Handheld Pulse Oximeter features:

• Streamlined design, aesthetic & generous
• Lightweight, easy operation
• 1.8 high definition LCD colour screen, Real-time showing of SpO2 waveform, SpO2 & PR value and intensity
• Unique digital SpO2 technology, fast, accurate, stable and strong anti-interference performance
• At least 48 hours parameter & trend data storage, maximum up to 999 measuring objects
• It could be connected with a PC to download and analyze/print data
• Suitable for adults, paediatrics, neonates
• Real-time clock, easy time setup, it could be set manually or via PC software
• Automatically recharge the battery at the connection of the device to the circuit
• 10-12 hours battery back-up after complete charge, Real-time indicator capacity
• Alarm in Acoustic and visual when the parameter is abnormal
• Surface and padding can be sterilized by disinfectant solution

Monitor Parameters

SPO2, PR

1. Oxyhemoglobin saturation (SpO2)

• Patient type: adult, paediatrics, neonates
• Measurement range: 0-100%
• Resolution: 1%
• Accuracy: ±2% during 70%-100%

2. Pulse rate (PR)

• Measurement range: 20 bpm-300 bpm
• Resolution: 1 bpm
• Accuracy: ±2 bpm

3. Working Environment

• Temperature Range
• Operating: 0℃ ~ 50℃
• Transport/Storage: -40℃ ~ 55℃

4. Relative Humidity

• Operating: 0% ~ 95% (noncondensing)
• Transport/Storage: 0% ~ 95% (noncondensing)

5. Electrical Specification

• Operating voltage: 100~240 VAC, 50/60Hz
• Consumption: ＜60VA

6. Quality Certificate

• Quality System: ISO13485:2003

Estimated Delivery: 5-10 days

Warranty:

• 1 Year
