МДЦ260Ф/13.2-2 (Автовосстанавливающиеся предохранители — PPTC)

Приобрести MINISMDC260F/13.2-2 от 1 штуки в Москве. Производитель LITTELFUSE.
На складе доступно 6000 штук.

117,00 ₽

Технические характеристики

Approval Agency	CSA, TUV, UL
Current – Hold (Ih) (Max)	2.6A
Current – Max	100A
Current – Trip (It)	5A
ECCN	EAR99
HTSUS	8533.40.8070
Moisture Sensitivity Level (MSL)	2A (4 Weeks)
Mounting Type	Surface Mount
Operating Temperature	-40°C ~ 85°C
Package	Tape & Reel (TR), Cut Tape (CT), Digi-Reel®
Package / Case	1812 (4532 Metric), Concave
Resistance – Initial (Ri) (Min)	15 mOhms
Resistance – Post Trip (R1) (Max)	50 mOhms
RoHS Status	ROHS3 Compliant
Series	PolySwitch®, miniSMD
Size / Dimension	0.181″ L x 0.128″ W (4.60mm x 3.24mm)
Thickness (Max)	0.060″ (1.52mm)
Time to Trip	5s
Type	Polymeric
Video File	Building Automation – Protect/Sense/Control Basic
Voltage – Max	13.2V
