MB2110-0000-0000 | Baseplate, 2-row, 10 data slots, 10 power slots, extended functions

The 2-row baseplates of the MBxxxx series are available in various lengths and are used to accommodate 1- and 2-row function modules. The data connectors provide 24В VВ DC or 48В VВ DC and EtherCAT for the connected modules. The power connectors supply 400…480В VВ AC and up to 848В VВ DC for the DC link. Optionally, data connectors can also be configured in the second row in addition to the power connectors. Potential equalization points and an optional diagnostic interface are provided on the baseplate.
