6090 Camera Laser Cutting Engraving Machine

Crafts Products 60*90cm Laser Machine With CCD Function Automatically Edge Cutting.

• Small and Medium machine size–very popular model.
• Machine can add with 60W, 80W, 100W and 150W laser tube, which can be used for engraving and cutting work.
• Laser Tube 80W, 100W and 150W all use RECI brand – one of the best laser tube brands in this industry.
• Machine color is optional.
• Transmit files directly in CorelDraw, AutoCAD etc.

Применение продукта

Monument (tombstone/gravestone) industry, model industry (construction models, aviation and navigation models and wooden toys), advertisement, décoration, art crafts, electronics, and electric appliances, etc.

Применимые материалы

Non-metal materials such as stone, marble, granite, gravestone, tombstone, acrylic, glass, ceramics, wood, bamboo, double colored boards, paper, and leather, etc.

Характеристики продукта

• The Camera in Automatic Camera Positioning Cutting Machine reflects very fast with high frame rate. It’s much easier to install and adjust. One time position fixing will be OK for total work.
• Has professional visual light source. During working process, it can automatically intake the pictures into computer by the visual system. Through treatment, it can automatically search for the work and position accurately to cut.

Технические характеристики

Characteristics Technology: CO2 laser

Material: for acrylics, for wood, for leather, for marble, for granite, for glass, for ceramics, for paper

Product handled: sheet

Associated function: engraving

Other characteristics: automatic, with CCD camera

X travel: 780 mm (31 in)

Y travel: 580 mm (23 in)

Cutting speed:

• Max.: 10,000 mm/min (6.562 in/s)
• Min.: 0 mm/min (0 in/s)

Laser power:

• Max.: 150 W
• Min.: 60 W
