SABIX® Rail Data

SABIX® Rail Data paired with overall copper screen tested acc. to EN 45545-2 Marking for SABIX® R 645 FRNC TP 66450325: SAB BRÖCKSKES · D-VIERSEN · SABIX® R 645 FRNC TP 3 x 2 x 0,25 mm² CE. SABIX® R 645 FRNC TP is a paired SABIX® Rail Data cable with overall copper screen that has good transmission rates and crosstalk attenuation. It is recommended for the internal wiring of rail vehicles acc. to EN 45545-2.

• halogen-free
• no flame propagation
• screened, good EMC characteristics
• flame retardant and self-extinguishing
• fulfils fire protection requirements R15 (EL1A) acc. to EN 45545-2 for hazard levels HL1-3
• fulfils fire protection requirements acc. to NFPA 130 section 8.6.7.1.1.1 and section 12.2.1 (1)
• tested acc. to American ASTM standard
• flame retardant acc. to UN/ECE R118
• good transmission rates and crosstalk attenuation
• Especially for use in rail vehicles

Conductor – bare copper strands with reference to IEC 60228, VDE 0295, class 5
Insulation – Special SABIX®
Colour code – with reference to DIN 47100
Stranding – pairwise, pairs in layers
Wrapping – foil
Screen – tinned copper braiding
Sheath material – Special SABIX®
Sheath colour – grey (RAL 7032)
Peak operating voltage –

Технические характеристики

Characteristics Typedata Format DIN

• Protection insulated, flame-retardant, with copper screen, self-extinguishing
• Configuration multi-strand, twisted pair, paired, multipair
• Core material copper
• Applications for railway applications
• Norms IEC, EN 45545
• Other characteristics flexible, halogen-free, ASTM

Nominal voltage

350 V, 500 V, 1,200 V, 1,500 V

Temperature

Max.: 90 °C (194 °F)

Min.: -40 °C (-40 °F)

Cross-section

0.14 mm², 0.25 mm², 0.34 mm², 0.5 mm², 0.75 mm² (0 in²)
