Измеритель сопротивления PRS-202 IET Labs

Additional Features:

• Manual control via thumbwheel switches standard
• Optional RS-232, Ethernet or IEEE-488 Interfaces
• Manual control via front panel and computer control via RS-232, Ethernet or IEEE-488.2.
• Decades: 7
• Resistance from 1 mΩ/step to 10 MΩ /step
• Accuracy: ±(0.01% + 15 mΩ) to ±(1% + 70 mΩ)
• Manganin wire for resistance values &lt, 1 Ω/step
• Precision metal film resistors for PRS-200 and PRS-201 for 1 Ω/step and over
• Sealed wirewound non-inductive resistors for PRS-202 for 1 Ω/step to 100 kΩ/step
• Precision metal oxide film resistors for 1 MΩ and higher steps for PRS-202

The PRS-202 programmable resistance substituter is a cost-effective solution for a computer-controlled decade box. Ideal for both laboratory and industrial applications requiring highly reliable and automated switching of resistance.

Технические характеристики
