The Matrix APS-4000A

The Matrix APS-4000A is an AC power supply, suitable for powers up to 350VA and can generate frequencies up to 250Hz. The voltage can be set to a maximum of 300V, single phase. The power supply has a clear display which shows the voltage, current, active power and frequency/power factor simultaneously. This allows you to read the most important parameters at a glance.

The APS-4000A is equipped with a soft start function, which protects it from the high inrush current of a load, e.g. a motor. This power supply is also resistant to an overload of 300% during 2s. In addition, the APS-4000A has a user-friendly interface, making it intuitive to use. With key lock M1, M2, M3, M4 and M5 five sets of memory can store the commonly used voltage V and frequency F, easy to recall them by one ke

Технические характеристики

• Power: 350 VA
• Voltage range: 0-150V, 0-300V
• Maximum current: 3A
• Frequency range: 45 – 250 Hz
• Setting accuracy: 10 mV/ 1m A / 10 mHz
• Load regulation: 1 %
• Protection: OCP, OTP, overload, short circuit
• Dimensions: 365 x 150 x 430 mm
• Weight: 12.7 kg

The Matrix APS-4000A is standard delivered with:

• Power cord
