IP3102-Bxxx | Fieldbus Box, 4-канальный аналоговый вход, напряжение, ±10 В В, 16 В бит, дифференциальный, M12

The IP3102 analog input module handles signals in the range from -10 to +10В V. The voltage is digitized to a resolution of 16В bits and transmitted, electrically isolated, to the higher-level automation device. The four input channels have differential inputs and possess a common, internal ground potential. The applied auxiliary voltage (which can be any value up to 30В VВ DC) is fed through to supply the sensor. It is thus possible, for instance, to supply a measuring potentiometer with 10В VВ DC from an external voltage source.
