IP2322-B310 | Fieldbus Box, 4-channel digital input + 4-channel digital output, PROFIBUS, 24В VВ DC, 3В ms, 2В A, M12

The IP2322-Bxxx digital I/O module combines four digital inputs and four digital outputs in one device. The outputs handle load currents of up to 2В A, are short-circuit-proof and protected against inverse polarity. The total current for all four outputs is limited to 4В A. This makes these modules particularly suitable for applications in which not all of the outputs are active at the same time or in which not all of the actuators draw 2В A signal current. The state of each signal is indicated by means of light emitting diodes. The signals are connected via M12 screw type connectors.
