Greenlee KA12-500 – ‘U’ Style Die for Aluminum Connectors, 500 KCMIL (MCM)

Description

The chart below contains information for Greenlee ‘U’ style dies designed for copper and aluminum.

‘U’ Style Dies ALUMINUM COPPER CABLE SIZE CAT. NO. COLOR CAT. NO. COLOR 8 AWG KA12-8 BLUE KC12-8 GRAY 6 AWG KA12-6 GRAY KC12-6 BLUE 4 AWG KA12-4 GREEN KC12-4 GRAY 2 AWG KA12-2 PINK KC12-2 BROWN 1 AWG KA12-1 GOLD KC12-1 GREEN 1/0 AWG KA12-1/0 TAN KC12-1/0 PINK 2/0 AWG KA12-2/0 OLIVE KC12-2/0 BLACK 3/0 AWG KA12-3/0 RUBY KC12-3/0 ORANGE 4/0 AWG KA12-4/0 WHITE KC12-4/0 PURPLE 250 KCMIL (MCM) KA12-250 RED KC12-250 YELLOW 300 KCMIL (MCM) KA12-300 BLUE KC12-300 WHITE 350 KCMIL (MCM) KA12-350 BROWN KC12-350 RED 400 KCMIL (MCM) KA12-400 GREEN KC12-400 BLUE 500 KCMIL (MCM) KA12-500 PINK KC12-500 BROWN 600 KCMIL (MCM) KA12-600 BLACK KC12-600 GREEN 750 KCMIL (MCM) KA12-750 YELLOW KC12-750 BLACK

The chart below shows several additional ‘U’ style dies and their corresponding Burndy number.

CAT. NO. BURNDY NO. CAT. NO. BURNDY NO. KD12-10 U-BG KD12-30 U-D3 KD12-11 U-O KD12-32 U-F KD12-12 U-C KD12-33 U-997 KD12-14 U-161 KD12-35 U-238 KD12-15 U-162 KD12-36 U-654 KD12-17 U-165 KD12-37 U-655 KD12-18 U-166 KD12-38 U-658 KD12-19 U-243 KD12-39 U-659 KD12-20 U-247 KD12-40 U-998 KD12-21 U-249 – –
