Фотодатчик Quadrant Cell, кремниевый, 190-1050 нм, резьба 8-32/M4 Модель: 2901

Технические характеристики

• Wavelength Range 190-1050 nm
• Sensor Size 3 x 3 mm
• Maximum Conversion Gain 102 to 106 V/W
• Transimpedance Gain 2×102 to 2×106 V/A
• Optical Input Free Space
• CW Saturation Power 30 mW per channel
• Analog Output X, Y, SUM
• Analog Output Voltage Range X & Y: ±2.5 V
  SUM: 0 to +2.5 V

• Connector, Analog Output Male BNC
• Analog Output Impedance 1 k
• Power Requirements ±15 V or 9V Battery
• Responsivity 0.5 A/W
• Bandwidth (-3 dB) 100 kHz (30 Hz for SUM)
• Detector Material Si
• Rise Time 4 s
