Enerpac RR1010 – General Purpose Hydraulic Cylinder, 11.1 Tons Capacity, 10′ Stroke

Description

Enerpac RR1010

• Max. cylinder capacity advance (tons): 11.1 | Capacity class (tonnage): 10 | Stroke: 10′
• Double acting
• Collar threads, plunger threads and base mounting holes for easy fixturing (on most models)
• Baked enamel finish for increased corrosion resistance
• Removable hardened saddles protect the plunger during lifting and pressing
• A built-in safety valve prevents accidental over-pressurization
• Plunger wiper reduces contamination, extending cylinder life

General Purpose Hydraulic Cylinder, 11.1 Tons Capacity, 10′ Stroke

Enerpac RR1010 is a Baked enamel finish for increased corrosion resistance with Removable hardened saddles to protect the plunger during lifting and pressing. It comes with a built-in safety valve that prevents accidental over-pressurization. Its Collar threads, plunger threads and base mounting holes for easy fixturing. Also, the Plunger wiper reduces contamination, extending cylinder life and CR400 is included on all models.

Think Safety

Manufacturers’ rating of load and stroke are maximum safe limits. Good practice encourages using only 80% of these ratings!

Pump Selection

A double-acting cylinder must be powered by a pump with a 4-way valve.

RR Series Comparison Table

Model NumberMaximum Operating Pressure (psi)Capacity Class (tonnage)Maximum Cylinder Capacity Advance (tons)Maximum Cylinder Capacity Retract (tons)Stroke (in)Collapsed Height A (in)Extended Height B (in)Return TypePlunger TypeRR1001310,000 100103.24813.1320.6333.75Double-Acting, Hydraulic ReturnSolidRR1001810,000 100103.24818.1327.0645.19Double-Acting, Hydraulic ReturnSolidRR100610,000 100103.2486.6314.0620.69Double-Acting, Hydraulic ReturnSolidRR101010,000 1011.1 4 1016.13 26.13Double-Acting, Hydraulic ReturnSolidRR101210,000 1011.1 4 12 1830Double-Acting, Hydraulic ReturnSolidRR150210,000 150153.5302.25 7.19 9.44Double-Acting, Hydraulic ReturnSolidRR150610,000 150153.5746.13 15.1921.31Double-Acting, Hydraulic ReturnSolidRR200610,000 200221112.5616.9422.94Double-Acting, Hydraulic ReturnSolidRR300610,000 300354.6190619.1325.13Double-Acting, Hydraulic ReturnSolid
