The GW Instek PEL-504-80-70

The GW Instek PEL-504-80-70 is a 350 W electronic load capable of 80 V and 70 A. This load has 4 static modes, namely current, resistance, voltage and power as well as 3 dynamic modes which are current, resistance and power. Furthermore, voltage, current and power are displayed simultaneously on the 5 digit display. This load allows for short-circuit testing in addition to automatic testing of overcurrent and overpower protection. The load also features a special battery discharge test function where discharge stop voltage, discharge capacity and discharge time can be set. Surge testing is also possible by simulating boot overshoot currents and transient currents that can occur when hot plugging. Reverse polarity detection is also available next to overvoltage, overcurrent, overpower and overtemperature protection. Voltage polarity can be set to a positive or negative value on the display. The communication interfaces consist of RS232 and USB.

Model overview

Model Power Input Voltage range Input Current range Resistance Slew rate Dimensions Weight Price
PEL-503-80-50 250 W 0 – 80 V 0 – 50 A 0.016 – 96 k 0.032 A/μs – 2 A/μs 205 x 123 x 477 mm 5.3 kg 1077.64 € Excl. VAT
PEL-504-80-70 350 W 0 – 80 V 0 – 70 A 0.0114 – 68.4 k 0.0464 A/μs – 2.90 A/μs 205 x 123 x 477 mm 5.3 kg 1216.49 € Excl. VAT
PEL-504-500-15 350 W 0 – 500 V 0 – 15 A 0.4 – 2.4 M 0.001 A/μs – 0.625 A/μs 205 x 123 x 477 mm 5.3 kg 1221.45 € Excl. VAT
PEL-507-80-140 700 W 0 – 80 V 0 – 140 A 0.0057 – 34.2 k 0.0096 A/μs – 6 A/μs 205 x 231 x 480 mm 10.3 kg 2048.72 € Excl. VAT
PEL-507-500-30 700 W 0 – 500 V 0 – 30 A 0.02 – 1.2 M 0.002 A/μs – 1.25 A/μs 205 x 231 x 480 mm 10.3 kg 2216 € Excl. VAT

Specifications

  • Static modes: CC, CR, CV, CP
  • Dynamic modes: CC, CP, CR
  • Protection: OPP, OCP, OVP, OTP
  • Interfaces: RS232, USB
  • Display: LCD

Комплект поставки

The PEL-504-80-70 includes:

  • Power cord
  • USB cable
  • RS232 cable
