Digilent MCC USB-2416-4AO PKG — комплект из термопары и USB-устройства сбора данных для измерения напряжения и модуля расширения AI-EXP32

Description

Digilent MCC USB-2416-4AO PKG

• MCC USB-2416-4AO USB DAQ device and AI-EXP32 expansion module bundle
• USB-2416-4AO features 32 SE/ 16 DIFF, analog inputs for measuring voltage or thermocouple measurements, 4 analog outputs, 8 digital I/O and 2 counter inputs
• AI-EXP32 expansion module provides an additional 32 SE/16 DIFF analog inputs and 16 digital I/O
• 24-bit resolution
• 1 kS/s sample rate

Thermocouple and Voltage Measurement USB DAQ Device and AI-EXP32 Expansion Module Bundle

The Digilent MCC USB-2416-4AO PKG is an MCC USB-2416-4AO USB DAQ device and AI-EXP32 expansion module bundled together. The USB-2416-4AO is ideal for higher channel count applications measuring voltage or thermocouples. The device features 32 SE/ 16 DIFF, 16-bit analog inputs for measuring voltage or thermocouples measurements (thermocouples are measured in DIFF mode), 1 kS/s sample rate, four analog outputs, eight digital I/O, and two counter inputs.

The AI-EXP32 is an expansion module that provides an additional 32 SE/16 DIFF analog inputs and 16 digital I/O. The AI-EXP32 supports all analog/thermocouple input and digital I/O features of the USB-2416 Series devices to which it is connected.

The USB-2416 Series docks directly to the AI-EXP32 with an expansion connector on each device. No additional cable is required. The AI-EXP32 receives power from the connected USB-2416 Series device.

Software support includes DAQami, an out-of-the-box application for data logging, visualization, and signal generation. Data can be viewed in real-time or post-acquisition on user-configurable displays. Drivers are included for the most popular applications and programming languages including Visual C++, Visual C#, Visual Basic.NET, DASYLab, LabVIEW, Linux, and Python.
