Comet T3319P — промышленный датчик температуры и влажности, выход RS232

Description

Comet T3319P

• Duraluminum probe for compressed air up to 25bars
• 1m cable
• Temperature and Humidity Transmitter
• RS232 serial output

Industrial Temperature and Humidity Transmitter, RS232 Output

Programmable temperature and humidity transmitter is equipped with temperature and relative humidity sensors. Measured values are also converted to other humidity interpretation – dew point temperature, absolute humidity, specific humidity, mixing ratio, or specific enthalpy. Degrees Celsius and Fahrenheit are user selectable. Transmitter contains a microprocessor-based control circuitry in a durable plastic case with connection terminals and sensors in a probe on a cable. Sensors are protected with a filter with stainless steel mesh. Large dual line LCD for simultaneous display of T+RH or other humidity interpretation is an advantage. Display is possible to switch off. Computerized design ensures temperature compensation of the humidity sensor and fails indication. State-of-the-art capacitive polymer sensor ensures excellent calibration long-term stability, inertia against water, and condensation. Transmitters are designed for use in non-aggressive environment.

Serial output RS232 – transmitter works with ModBus RTU communication protocol or with Advantech ADAM compatible protocol. Protocol is user selectable in special configuration mode by means of the PC. Serial link enables to read actual readings and modify transmitter configuration. Instrument works always in slave mode, i.e. responds only to master device query. Transmitters have the address space available from 1 to 255. Communication speed is 110 to 115200Bd.

Applications

• Building HVAC management
• Building HVAC automation
• Warehouses
• Glasshouses
• Manufacturers
• Museums, archives, galleries
• Air-conditioned rooms
• Weather stations

Software

• Comet Database
• Complex solution for data acquisition and analysis. Easy to use and high flexible Database software for Comet Transmitters and Regulators.
• Sensor RS485/232 utility
• Allows communication of sensors with RS485/RS232 output and sending data to Comet Database.
• T-Sensor software
• Free configuration utility for Comet Transmitters and Regulators.
• Sensor Reader software
• Basic data acquisition utility for Comet Transmitters and Regulators. Software is free for download.
