Technical dataKL6031
Technology RS232
Data transfer channels 2 (1/1), TxD and RxD, full duplex
Data transfer rates 4800…115,200 baud, default: 9600 baud, 8 data bits, no parity and one stop bit
Bit distortion <>
Line impedance –
Cable length max. 15 m
“0” signal voltage -18…-3 V
“1” signal voltage 3…18 V
Power supply via the K-bus
Current consumption K-bus typ. 55 mA
Current consumption power contacts – (no power contacts)
Electrical isolation 500 V (K-bus/signal voltage)
Data buffer 1024В bytes receive buffer, 128В bytes transmit buffer
Bit width in the process image input/output: 22 x 8 bit user data, 2 x 8 bit control/status (up to 22 byte user data are possible)
Configuration no address setting, configuration via Bus Coupler or controller
Special features high interference immunity, electrically isolated signals
Weight approx. 80 g
Operating/storage temperature -25…+60°C/-40…+85°C
Relative humidity 95%, no condensation
Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission conforms to EN 61000-6-2/EN 61000-6-4
Protect. rating/installation pos. IP20/variable
Pluggable wiring for all KSxxxx Bus Terminals
Approvals/markings CE, UL, ATEX, IECEx, DNV GL
Ex marking ATEX:
II 3 G Ex ec IIC T4 Gc
IECEx:
Ex ec IIC T4 Gc
