WB2.5-6SL

General specification Core Material: Ferrite Weight: 0.38 – 0.40 g Packaging: (SM version): 500 per 13 reel, Plastic tape: 24 mm wide, 0.42 mm thick, 20 mm pocket spacing, 6.6 mm pocket depth, (TH version): 70 per tube Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More Info

1125,00 ₽

Артикул: WB2.5-6SLD Категорий: Products, Transformers, WB_SMT, WB2-5-6SL, Wideband RF Transformers

Описание

Specifications

Electrical specifications at 25C. Measurements are referenced to 50 Ohms.

No taps

Part number 1 (Hover for schematics)	L min per winding (H) 2		DCR max (mΩ) 3		Imp. ratio pri:sec 4	Current rating (mA)	Insertion loss (db)	Bandwidth (MHz)	Isolation Voltage (Vrms)	Schematic
Part number 1 (Hover for schematics)	Pri	Sec	Pri	Sec	Imp. ratio pri:sec 4	Current rating (mA)	Insertion loss (db)	Bandwidth (MHz)	Isolation Voltage (Vrms)	Schematic
WB2.5-6SL_	30	75	100	130	1 : 2.5	250	0.26	0.08 225	500	A
