1812TRX Series

General specification Core Material: Ferrite Weight: 120 – 130 mg Packaging: 600/7 reel, 2200/13 reel Plastic tape: 12 mm wide, 0.25 mm thick, 8 mm pocket spacing, 3.25 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.
