Такисава ТМХ-линейка

Технические характеристики

Specifications

TMX Models

• TMX-4000ST


  Specification	Detail
  Max. Turning Length	59.06″
  Maximum Turning Diameter	19.69″
  Bar Capacity	3.15″
  Chuck Size	10″
  X-Axis Travel (Tool Spindle)	23.82″
  Y-Axis Travel (Tool Spindle)	10.24″
  Z-Axis Travel (Tool Spindle)	59.06″
  Number of Turrets	12
  Type of Turret	Tool Spindle with ATC
  ATC Storage Capacity	40 (opt. 80, 120)
  Spindle Speed	12000
  Max. Tool Diameter	3.54″ (4.92″)
  Max. Tool Length	15.75″

• TMX-2000


  Specification	Detail
  Max. Turning Length	22.24″
  Maximum Turning Diameter	19.69″
  Bar Capacity	2.01″
  X-Axis Travel	24.8″
  Y-Axis Travel	9.06″
  Z-Axis Travel	27.17″
  Number of Turrets	1
  Type of Turret	ATC
  Number of Attachable Tools	1
  Spindle Speed	12000
  ATC Time (TtoT)	2
  Max. Tool Diameter	4.92″
  Max. Tool Length	11.81″

• TMX-2000S


  Specification	Detail
  Max. Turning Length	22.24″
  Maximum Turning Diameter	19.69″
  Bar Capacity	L:65 2.56″, R:51 2.01″
  X-Axis Travel	24.8″
  Y-Axis Travel	9.06″
  Z-Axis Travel	27.17″
  Number of Turrets	1
  Type of Turret	ATC
  Number of Attachable Tools	1
  Spindle Speed	12000
  ATC Time (TtoT)	2
  Max. Tool Diameter	4.92″
  Max. Tool Length	11.81″
