ПОЭ70П-33

General specification Core Material: Ferrite Weight: 2.05 g, 3.85 g, 6.15 g Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.

450,00 ₽

Артикул: POE70P-33LD Категорий: POE70P-33, POExxP, Power Over Ethernet, Power Transformers, Products, Transformers

Описание

Specifications

Electrical specifications at 25C.

Part number 1 (Hover for schematics)	Power (W)	Inductance at 0A (H) 2 (Tolerance: &plusmn,10%)	Inductance min at 0.65 A (H)	DCR max (Ω) 3			Leakage Inductance max (H) 4	Turns Ratio 5	Isolation Voltage (Vrms) 6	Secondary Output (V, A)
Part number 1 (Hover for schematics)	Power (W)	Inductance at 0A (H) 2 (Tolerance: &plusmn,10%)	Inductance min at 0.65 A (H)	Pri	Sec	Bias	Leakage Inductance max (H) 4	Pri : Sec : Bias	Isolation Voltage (Vrms) 6	Secondary Output (V, A)
POE70P-33L_	7	155	140	0.414	0.036	0.822	4.00	1 : 0.19 : 0.667	1500	3.3 V , 2.12 A
