POE51Q-12

General specification Core Material: Ferrite Weight: 6.5 – 8 g Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering.

675,00 ₽

Артикул: POE51Q-12ED Категорий: POE51Q-12, POExxQ, Power Over Ethernet, Power Transformers, Products, Transformers

Описание

Specifications

Electrical specifications at 25C.

Part number (Hover for schematics)	Power (W)	Inductance at 0A (H) 1 (Tolerance: &plusmn,10%)	Isat (A) 2	DCR max (mΩ)			Leakage Inductance max (H) 3	Turns Ratio	Isolation Voltage (Vrms) 4	Secondary Output (V, A) 5
Part number (Hover for schematics)	Power (W)	Inductance at 0A (H) 1 (Tolerance: &plusmn,10%)	Isat (A) 2	Pri	Sec	Aux	Leakage Inductance max (H) 3	Pri : Sec : Aux	Isolation Voltage (Vrms) 4	Secondary Output (V, A) 5
POE51Q-12E_	51	22.2	4.7	35.0	18.0	85.0	0.14	1 : 0.5 : 0.5	1500	12 V , 3.9 A
