HA4061-AL

General specification Core Material: Ferrite Weight: 37.3 g Packaging: 64 per tray Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested with pure water or alcohol only. For other solvents, see Doc787_PCB_Washing.pdf.

900,00 ₽

Категорий: HA4061, HA4061-AL, Power Converter Transformers, Power Transformers, Products, Transformers

Описание

Specifications

Electrical specifications at 25C.

Part number (Hover for schematics)	Inductance at 0A (H) 1 (Tolerance: &plusmn,10%)	Inductance min at 5 A (H)	DCR max (Ω) 2		Leakage Inductance max (H) 3	Turns Ratio 4	Volt-time product (V-s)	Isolation Voltage (Vrms) 5
Part number (Hover for schematics)	Inductance at 0A (H) 1 (Tolerance: &plusmn,10%)	Inductance min at 5 A (H)	Pri	Sec	Leakage Inductance max (H) 3	Pri : Sec	Volt-time product (V-s)	Isolation Voltage (Vrms) 5
HA4061-AL	125.0	112.5	0.203	1.400	9.17	1 : 3	625	3000
