HA3809-AL

General specification Core Material: Ferrite Weight: 11.4 – 11.8 g Packaging: 175 per 13 reel Plastic tape: 44 mm wide, 0.4 mm thick, 32 mm pocket spacing, 11.9 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested with pure water or alcohol only. For other solvents, see Doc787_PCB_Washing.pdf.

1125,00 ₽

Артикул: HA3809-ALD Категорий: GA3568, HA3809-AL, Power Over Ethernet, Power Transformers, Products, Transformers

Описание

Specifications

Electrical specifications at 25C.

Part number 2 (Hover for schematics)	Inductance at 0A (H) 3 (Tolerance: &plusmn,10%)	Inductance min at 3.9 A (H)	DCR max (Ω) 4				Leakage Inductance max (nH) 5	Turns Ratio 6	Isolation Voltage (Vrms) 7
Part number 2 (Hover for schematics)	Inductance at 0A (H) 3 (Tolerance: &plusmn,10%)	Inductance min at 3.9 A (H)	Pri	Sec	Bias	Sync	Leakage Inductance max (nH) 5	Pri : Sec : Bias : Sync	Isolation Voltage (Vrms) 7
HA3809-AL_	30	25	0.042	0.010	0.165	0.165	680	1 : 0.176 : 0.29 : 0.29	1500
