GA3459-BL

General specification Core Material: Ferrite Weight: 24.2 – 27.5 g Packaging: 24 per tray Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested with pure water or alcohol only. More info.

2475,00 ₽

Категорий: Capacitor Charging, GA3459, GA3459-BL, Power Transformers, Products, Transformers

Описание

Specifications

Electrical specifications at 25C.

Part number (Hover for schematics)	Inductance at 0A (H) 1 (Tolerance: &plusmn,10%)	Inductance min at 20 A (H)	DCR max (mΩ) 2		Leakage Inductance max (H) 3	Turns Ratio 4	Isolation Voltage (Vrms) 5
Part number (Hover for schematics)	Inductance at 0A (H) 1 (Tolerance: &plusmn,10%)	Inductance min at 20 A (H)	Pri	Sec	Leakage Inductance max (H) 3	Pri : Sec	Isolation Voltage (Vrms) 5
GA3459-BL	5.0	4.3	7.7	515	0.10	1 : 10	1500
