C1154-BL

General specification Core Material: Ferrite Weight: 4.9 g Packaging: 200 per 13 reel Plastic tape: 44 mm wide, 0.35 mm thick, 28 mm pocket spacing, 9.6 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.

0,00 ₽

Категорий: C1154, C1154-BL, Power Over Ethernet, Power Transformers, Products, Transformers

Описание

Specifications

Electrical specifications at 25C.

Part number (Hover for schematics)	Inductance at 0A (H) 1 (Tolerance: &plusmn,10%)	Inductance min at 0.25 A (H)	DCR max (Ω)					Leakage Inductance max (H) 2	Turns Ratio	Isolation Voltage (Vrms) 3
Part number (Hover for schematics)	Inductance at 0A (H) 1 (Tolerance: &plusmn,10%)	Inductance min at 0.25 A (H)	Pri	Sec1	Sec2	Drive	Aux	Leakage Inductance max (H) 2	Pri : Sec1 : Sec2 : Drive : Aux	Isolation Voltage (Vrms) 3
C1154-BL_	255.0	229.5	0.335	0.020	0.017	0.200	0.745	5.0	1 : 0.1 : 0.075 : 0.125 : 0.425	1500
