0402DC-9N4

General specification Core Material: Ceramic Weight: 0.7 – 1.0 mg Packaging: 2000 or 10,000 per 7 reel, Paper tape: 8 mm wide, 0.68 mm thick, 2 mm pocket spacing Temperature coefficient of inductance: +25 to +125 ppm/°C Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: PCB washing Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info
