ZD2087-AE

General specification Core Material: Ferrite Weight: 6.99 g Packaging: 150 per 13 reel Plastic tape: 44 mm wide, 0.5 mm thick, 28 mm pocket spacing, 14.6 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering.

0,00 ₽

Категорий: Power Converter Transformers, Power Transformers, Products, Transformers, ZD2087, ZD2087-AE

Описание

Specifications

Electrical specifications at 25C.

Part number (Hover for schematics)	Power (W)	Inductance at 0A (H) 1 (Tolerance: &plusmn,10%)	Isat (A) 2	DCR max (Ω)		Leakage Inductance max (H) 3	Turns Ratio	Isolation Voltage (Vrms) 4	Secondary Output (V, A)
Part number (Hover for schematics)	Power (W)	Inductance at 0A (H) 1 (Tolerance: &plusmn,10%)	Isat (A) 2	Pri	Sec	Leakage Inductance max (H) 3	Pri : Sec	Isolation Voltage (Vrms) 4	Secondary Output (V, A)
ZD2087-AED	9.9	13.5	8.0	0.02	0.293	0.15	1 : 2.555	1500	30 V , 0.33 A
