XEL3530-231

General specification Core Material: Composite Weight: 0.15 – 0.17 g Packaging: 500/7 reel, 2500/13 reel Plastic tape: 12 mm wide, 0.23 mm thick, 8 mm pocket spacing, 3.1 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Three reflows at &gt,217C for 90 seconds (+260C &plusmn,5C for 20 40 seconds), allowing parts to cool to room temperature between Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.

225,00 ₽

Артикул: XEL3530-231MEC Категорий: Molded Inductor, Power, Products, Shielded Inductors, XEL, XEL3530, XEL3530-231

Описание

Specifications

Electrical specifications at 25C. Operating voltage 0 – 80 V

Part number 1	Inductance (nH) 2 (Tolerance: &plusmn,20%)	DCR (mΩ) 3		SRF typ (MHz) 4	Isat (A) 5			Irms (A) 6
Part number 1	Inductance (nH) 2 (Tolerance: &plusmn,20%)	typ	max	SRF typ (MHz) 4	10% drop	20% drop	30% drop	20C rise	40C rise
XEL3530-231ME_	230	4.2	4.9	211	5.2	7.8	10.6	12.6	17.2

Каталог

AMP8051-Ex3z | Распределенный сервопривод 4,60 Нм (M0), F5 (104В мм)

AF1115-1xxx | Economy variable frequency drive, single-phase, single-axis module, 1.5В kWNew
