XAL6060-223

General specification Core Material: Composite Weight: XAL6030: 0.60 – 0.70 g, XAL6060: 1.0 – 1.6 g Packaging: XAL6030: 400/7reel, 1500/13 reel Plastic tape: 16 mm wide, 0.4 mm thick, 12 mm pocket spacing, 3.12 mm pocket depth XAL6060: 250/7 reel, 750/13 reel Plastic tape: 16 mm wide, 0.4 mm thick, 12 mm pocket spacing, 6.23 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.
