WBC1-1TL

General specification Core Material: Ferrite Weight: 68.0 – 88.8 mg Packaging: 750/7reel, 2500/13 reel Plastic tape: 12 mm wide, 0.3 mm thick, 8 mm pocket spacing, 2.9 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info

675,00 ₽

Артикул: WBC1-1TLC Категорий: Products, WBC1-1TL, ВБК, Трансформеры, Широкополосные ВЧ-трансформаторы

Описание

Specifications

Electrical specifications at 25C. Measurements are referenced to 50 Ohms.

Part number 1 (Hover for schematics)	L min per winding (H) 2		Test frequency (kHz)	DCR max (mΩ) 3		Imp. ratio pri:sec 4	Current rating (mA)	Insertion loss (db)	DC imbalance 5	Bandwidth (MHz)	Isolation Voltage (Vrms)	Schematic	Color dot
Part number 1 (Hover for schematics)	Pri	Sec	Test frequency (kHz)	Pri	Sec	Imp. ratio pri:sec 4	Current rating (mA)	Insertion loss (db)	DC imbalance 5	Bandwidth (MHz)	Isolation Voltage (Vrms)	Schematic	Color dot
WBC1-1TL_	9.5	9.5	100	75.0	75.0	1 : 1	250	0.58	36.0	0.25 750	300	B	Brown
