WA8582-AL

General specification Core Material: Ferrite Weight: 0.95 g Packaging: 600/13 reel, Plastic tape: 24 mm wide, 0.37 mm thick, 16 mm pocket spacing, 6.1 mm pocket depth Soldering/Washing Moisture Sensitivity Level (MSL): 1 (unlimited floor life at Resistance to soldering heat: Max three 40 second reflows at +260C, parts cooled to room temperature between cycles Refer to Soldering Coilcraft Components before soldering. PCB Washing: Tested to MIL-STD-202 Method 215 plus an additional aqueous wash. More info.

675,00 ₽

Артикул: WA8582-ALD Категорий: Isolation, Power Transformers, Products, Transformers, WA8582, WA8582-AL

Описание

Specifications

Electrical specifications at 25C.

Part number 1 (Hover for schematics)	Power (W) 2	Pri / Sec Voltage (V)	Inductance at 0A (H) 3 (Tolerance: &plusmn,25%)	DCR max (Ω) 4		Turns Ratio	Volt-time product (V-s) 5	Isolation Voltage (Vrms) 6
Part number 1 (Hover for schematics)	Power (W) 2	Pri / Sec Voltage (V)	Inductance at 0A (H) 3 (Tolerance: &plusmn,25%)	Pri	Sec	Pri : Sec	Volt-time product (V-s) 5	Isolation Voltage (Vrms) 6
WA8582-AL_	2	5 / 5	136.8	0.310	0.475	1 : 1.33	22.7	1500
